16 Core Fiber Optical Termination Box

16 Core Fiber Optical Termination Box

JUNPU 16 Core Fiber Optical Termination Box, model: FAT-16C fiber access termination box is able to hold up to 16 subscribers. It is used as a termination point for the feeder cable to connect with the drop cable in the FTTx network system. It integrates fiber splicing, splitting, distribution, storage, and cable connection in one solid protection box.


Specifications of 16 Core Fiber Optical Termination Box

MaterialSizeMax CapacityWeight
PC+ABS325x275x95mmSC 16 portsPLC 1X8 SC1.0kg


Features of 16 Core Fiber Optical Termination Box

  • Water-proof design with IP-66 Protection level.

  • Integrated with splice cassette and cable management rods. Manage fibers in a reasonable fiber radius condition.

  • Easy to maintain and extend the capacity.

  • Fiber bend radius control is more than 40mm.

  • Suitable for the fusion splice or mechanical splice.

  • 2 pcs of 1*8 Splitter can be installed as an option.

  • Efficient cable management.

  • 16 ports cable entrance for the drop cable.


Application of 16 Core Fiber Optical Termination Box

  • Widely used in FTTH access networks.

  • Telecommunication Networks

  • CATV Networks

  • Data communications Networks

  • Local Area Networks


16 core fiber optical termination box
