SCUPC Cassette PLC Splitter

SCUPC Cassette PLC Splitter

splitter cassette

Optical fiber splitter is a type of optical power management device that is fabricated using silica optical waveguide technology. It features small size, high reliability, wide operating wavelength range and good channel-to-channel uniformity, and is widely used in PON networks to realize optical signal power splitting.


Specifications of SCUPC Cassette PLC Splitter


Parameters1×21×41×81×161×321×64
Operating Wavelength (nm)1260~1650
Fiber TypeG657A or customer specified
Insertion Loss (dB)(P/S Grade)3.8/4.07.1/7.310.2/10.513.5/13.716.5/16.920.5/21.0
Loss Uniformity (dB)0.40.60.81.21.52
Return Loss (dB) (P/S Grade)55/5055/5055/5055/5055/5055/50
Polarization Dependent loss0.20.20.20.250.30.35
Directivity (dB)555555555555
Wavelength Dependent Loss0.30.30.30.50.50.5
Temperature Stability(-40~85 ℃)(dB)0.40.40.40.50.50.5
Operating Temperature (℃)-40~85
Storage Temperature (℃)-40~85


Features of SCUPC Cassette PLC Splitter

  • Good uniformity and low insertion loss

  • Low Polarization Dependent Loss

  • Excellent Mechanical

  • Operating environment: -40ºC to +85ºC

  • Fiber input: 0.9mm or 250μm fiber for choice


Application of SCUPC Cassette PLC Splitter

  • Fiber optic equipment & systems

  • CATV networks

  • Data communications

  • Passive Optical Networks
