GJYXFCH Fiber Optical Drop Cable

GJYXFCH Fiber Optical Drop Cable

The FTTH drop cables are with flame retardant cable jacket and with supporting wire, this cable has strengthen members inside for supporting the whole body. The drop ftth optical fiber cable is with special structure to easily pull the fibers out from the cables, the FTTH drop cables are ideal to use for direct installation into the rooms, especially good for being used in homes and offices.


Specifications of GJYXFCH Fiber Optical Drop Cable

ItemDescription
Cable Diameter(2.0±0.1) ×(5.1±0.2)mm
Approx. Cable Diameter(2.0×3.0)±0.1mm
Approx. GFRP Sheath Outer Diameter2.0±0.1mm
Approx. Cable Net Weight18.5kg/km
Strength MemberMaterialGFRP
Outer Diameter0.5±0.01mm
Steel WireMaterialPhosphating Steel Wire
Diameter1.0±0.02mm
Optical FiberTypeITU-T G .657A1
Numbers1
LSZH Sheath of CableMaterialLSZH
Fiber Attenuation coefficient in CabledB/km(1310nm)≤0.4dB/km
dB/km(1550nm)≤0.3dB/km


Features of GJYXFCH Fiber Optical Drop Cable

  • Suitable for indoor or outdoor use.

  • Special low-bend-sensitivity fiber provides high bandwidth and excellent communication transmission property.

  • Simple structure, light weight and high practicability.

  • Low smoke, zero alogen and flame retardant sheath.


Application of GJYXFCH Fiber Optical Drop Cable

  • Ftth

  • Telecom network

  • Data network
