FODB-2F 4 Core Fiber Distribution Box

FODB-2F 4 Core Fiber Distribution Box

JP-I1-2OA fiber access termination box is able to hold up to 2 subscribers. It is used as a termination point for the feeder cable to connect with drop cable in FTTx network system. It integrates fiber splicing, splitting, distribution, storage and cable connection in one solid protection box.


Specifications of FODB-2F 4 Core Fiber Distribution Box

Model

Size

(mm)

Material

Capacity

Dsecription

Color

Optical cable ports

Mounting way

FODB-2F

175x122x31

PC+ABS

2 Core

SC – 2 ports

White/black

1-Φ8mm

Wall / Pole


Features of FODB-2F 4 Core Fiber Distribution Box

  • Water-proof design with IP-66 Protection level.

  • Integrated with splice cassette and cable management rods.

  • Manage fibers in a reasonable fiber radius condition.

  • Easy to maintain and extend the capacity.

  • Fiber bend radius control more than 40mm.

  • Suitable for the fusion splice or mechanical splice.

  • 1*2 Splitter can be installed as an option.

  • Efficient cable management.

  • 2 ports cable entrance for drop cable.


Application of FODB-2F 4 Core Fiber Distribution Box

  • FTTH, FTTB, FTTC

  • Telecommunication Network

  • Local Area Network

  • CATV
